Jay Chou Nanning Concert | Reyn Audio & ACME Audio and Lighting Support

April 25, 2026

April 17–19, 2026. Jay Chou's Carnival II tour held three shows at Guangxi Sports Center. The event coincided with the Guangxi March 3rd folk festival, with Zhuang ethnic cultural elements integrated into the show.

Full technical support for all sound and lighting equipment is provided by our team to guarantee stable performance throughout the show.

I. Reyn Audio Sound System | Full-Coverage Stable Sound Field

Stadiums are open with long throw distances, making sound field calibration difficult. This show used a full Reyn Audio setup : RAFALE15, RAFALE2, RAFALE3 line arrays, CANNON218 and RAFALE3S subwoofers, ABRAMS monitors, R1/R2/RA1/RA2 amplifier racks, and the TURANDOT acoustic system platform. This achieved full coverage with no dead zones and consistent sound quality.

1. Pre-Show Sound Field Simulation

On-Site System Report

Sound Field Layout Plan

SPL Sound Pressure Rendering Map

2. Main PA System

Center stage: RAFALE2 line arrays. Main PA: RAFALE15 line arrays. Subwoofers: CANNON218.

RAFALE15: stable long-distance projection, strong mid-lows. RAFALE2: clear high-frequency detail. Together they cover the floor and main stands, accurately reproducing vocals, instruments, and ethnic vocals.

3. Side Fill: Eliminating Dead Zones

Layered side fill on both sides of the venue:

- Side 1: 18 RAFALE15

- Side 2: 16 RAFALE15

- Side 3: 6 RAFALE2

- Side down: 4 RAFALE2

This fills side gaps, prevents sound field dropouts, and keeps audio balanced everywhere.

4. Low-Frequency System

Stage front: CANNON218 subwoofers with RAFALE2 line arrays, cardioid configuration. Clean, powerful lows for rock, rap, and adapted ethnic tracks. Reduces stage low-frequency interference, improving sound field clarity.

5. Front Fill: Restoring Vocal Detail

RAFALE2 line arrays deployed in the front floor rows. Fixes the front dead zone from elevated Main PA. Balances VIP area sound field. Clearly reproduces vocal detail and live improvisation.

6. Delay System: Unifying Far-Field Sound

Eight groups of RAFALE2 delay towers:

- 2 groups behind FOH, 12 speakers each

- 6 groups at far stands, 8 speakers each

Syncs with main stage audio. Solves long-distance delay and attenuation. Far-end sound stays synchronized and undistorted.

7. Stage Monitors: Stable Live Performance

Monitor system: ABRAMS wedges, RAFALE3 line arrays, RAFALE3S subwoofers. Gives performers accurate, true-to-stage audio. Supports live improvisation, chorus interaction.

8. Amplifier System: Stable Audio Output

RA1 and RA2 amplifier racks handle full-range audio amplification and signal processing. Dante network redundancy prevents signal dropouts. Shock-resistant build for touring. Low-distortion output preserves original sound character.

II. ACME Lighting System | Standardized Outdoor Stage Lighting

1. Key Light: True Color Reproduction

AECO 30 IP: 1800W, CRI Ra≥95. Accurate skin tone reproduction. Wide zoom range for spot and flood applications.

2. Waterproof Beam: Outdoor-Ready

PHOTON HYBRID 500: IP-rated hybrid laser moving head. Narrow beam, strong penetration. Multi-step zoom for complex outdoor conditions.

ARES IP: waterproof beam light. High output, rich color adjustment. IP66 rating for all-weather outdoor operation.

3. Effects Lighting: Rich Stage Layers

TORNADO, CYCLONE, SUPER DOTLINE, BLINDER LINE 10 IP: multi-function effects lights. Beam, strobe, wash integrated. Creates dynamic stage visuals.

PIXEL LINE SLIM: pixel bar light with individual pixel control. Used as foot lights to eliminate facial shadows and outline stage edges.

4. Wash Lighting: Matching Stage Mood

HYPERZONE: switchable between beam and soft wash. Adapts to multiple music styles.

PULSAR PLUS S2: dual-sided effects light. Full function set with adjustable rotation and haze. Fits various stage atmospheres.

5. Strobe Lighting: Boosting Stage Energy

LIGHTNING X, HAIL: zone-controllable strobes. Soft flash and burst flash modes. Matches song rhythm to heighten stage atmosphere.

For the Nanning shows, Reyn Audio delivered stable, balanced sound and ACME delivered rich, professional lighting. Both brands under Foshan Yifeng continue to provide professional audio and lighting equipment, supporting Jay Chou's Carnival tour with high-quality stage production.
