Number of output channels

• 4个单声道

Total peak output

• 3,600W

Maximum output peak voltage

• 80V

Maximum output power

• 4x800W@立体声8Ω；4x1,200W@立体声4Ω；2x1,800W@桥接模式8Ω

Frequency response

• 20Hz-20KHz(<±0.5dB,1W@8Ω)

Total harmonic distortion

• 典型值:0.05%(10%额定输出功率,1kHz,8Ω)

Noise level

• <-65dB(A计权,20Hz-20kHz,8Ω)

Crosstalk suppression

• >75dB(低于额定功率,20Hz-1kHz,8Ω)

Input impedance

• 20kΩ(平衡),10kΩ(非平衡)

Maximum input level allowed

• +22dBu

Input signal

• Analog

Protection

• 过热压限、过载保护、输出直流保护

Speaker management

• REYNAUDIO品牌K系列 ,RA系列 ,B系列扬声器数据设置

Control and monitoring software

• REYNAUDIO AMP Controller

Digital Signal Processor (DSP)

• ADI音频专用DSP

Standard delay time (analog input)

• 1.52ms

Adjustable delay time

• 0-160ms

Sampling rate

• 96 kHz/24 Bit ADC/24 Bit DAC

Equalizer

• 7-band PEQ

Limiter

• 峰值限幅器

Rated voltage

• 100-240V(±10%) ,50/60Hz 带有功率因数校正(PFC)的开关模式电源

Input ports

• 4个3针XLR端口模拟输入

Control port

• 1个100M以太网口RJ45 ,通讯控制信号

Output ports

• 2x 4-points Speakon®

Power input port

• IEC插头

Power switch

• 实体开关

Front display panel

• 1.8寸TFT液晶显示屏清晰显示系统状态，加按键控制

Finish material1

• 高强度铝镁合金外壳，表面烤漆工艺，加氧化面板处理

Operating temperature

• Operating temperature: 0°-40℃

Cabinet dimension(WxHxD)

• 483x45x299 mm
  (19.0"x1.8"x11.8")

Net Weight

• 5.4 kg (11.9 lbs)

Article number

• 12120603209372
