Output Channels

• 2 mono bridgeable per ch. pair

Total Peak Power

• 3,600W

Max. Output Voltage

• 98V

Max. Output Power

• 2x1,200W RMS @8Ω (Stereo mode)
  2x1,800W RMS @4Ω (Stereo mode)
  1x3,600W RMS @8Ω (Bridge mode)

Bandwidth

• 20Hz-20KHz(<±0.5dB,1W@8Ω)

THD+N

• Typical value:0.05% (10% nominal output power,1 kHz,8Ω)

Noise Floor

• <-65 dB (A weight,20 Hz - 20 kHz,8Ω)

Crosstalk

• 20kΩ (balanced)
  10kΩ (non-balanced)

Maximum Input Level

• +22dBu

Input Signal

• Analog

Protection

• overheat voltage limit, overload protection, output DC protection

Loudspeaker Management

• Data setup for all REYNAUDIO brand speakers

Control & Monitoring Software

• REYNAUDIO AMP Controller

DSP (Digital Signal Processor)

• Analog Devices audio dedicated DSP

System Latency (Analog Input)

• 1.52ms

Adjustable Delay

• 0-160ms

Sampling Rate

• 96 kHz/24 Bit ADC/24 Bit DAC

Equalization (EQ)

• 7-band PEQ

Protection Limiters

• Peak limiter

Mains Voltage

• 100-240V(±10%) , 50/60Hz switching mode power supply with power factor correction (PFC)

Signal Interfaces

• 4 x 3-pin XLR analog inputs

Control Ports

• 1 x 100Mbps Ethernet port RJ45 ,communication control signals

Output Connectivity

• 2x 4-points Speakon®

Mains Connector

• IEC plug

Power Switch

• Physical power switch

Front Panel Display

• 1.8-inch TFT LCD color display for real-time telemetry, backed by physical navigation buttons

Housing Finish

• High-grade aluminum-magnesium alloy with powder-coated finish

Operating Temperature

• 0°-40℃

Net Weight

• 5.4 kg (11.9 lbs)

Product Code

• 12120703209371

Dimensions (W x H x D) mm

• 483x45x299
  (19.0"x1.8"x11.8")
