K2 High-Performance Two-Way Loudspeaker | The Versatile Acoustic Partner for Professional Venues
Acoustic Design: Precision Control, Balanced Coverage
K2 Pairing a high-excursion 12-inch low-frequency transducer with a 1.7-inch high-frequency compression driver, the electro-acoustic topology integrates a precision crossover network and optimized waveguide to execute flawless frequency management. Punchy, articulate low-mids unite seamlessly with transparent highs, eliminating distortion to simultaneously satisfy vocal clarity and dynamic music reproduction.
Providing a controlled 90°×60° dispersion pattern concentrates acoustic energy directly into the listening plane, guaranteeing uniform sound pressure level (SPL) and pristine tonal accuracy from the central axis to venue boundaries to eliminate coverage inconsistencies.
Generating a robust peak SPL of 132 dB across a wide 45 Hz – 18 kHz frequency bandwidth, this enclosure offers broad deployment flexibility. Functioning independently as a high-definition full-range unit or combined with K18 / K218 subwoofers via dedicated 3-way system presets, it extends low-frequency headroom to effortlessly master diverse acoustic environments.
Structural Integrity: Solid Craftsmanship, Total Enclosure Protection
K2 Constructed from high-density multi-ply birch plywood, the cabinet couples extreme structural rigidity with excellent acoustic damping properties to suppress internal resonance and withstand rigorous transportation handling.
A heavy-duty steel front grille protects internal components against dust and physical impacts, while a durable black polyurea protective coating yields superior corrosion and wear resistance to sustain long-term operation while lowering lifecycle maintenance overhead.
Internal transducers bond to the chassis using precision-machined metal hardware, managing mechanical displacement during sustained high-excursion operation to maintain uncompromised acoustic fidelity.
Deployment Versatility: Flexible Rigging, Broad Application Adaptability
K2 Supporting horizontal and vertical multi-angle orientation via a dedicated rigging system, this enclosure easily accommodates single-point suspension or ground-stacked configurations. Recessed connection panels protect the interface from impact, featuring industrial-grade SpeakON® NLT4 M connectors to ensure pristine signal path transmission and rock-solid connection reliability.
Applicable across theaters, auditoriums, Livehouses, performing arts centers, high-end KTVs, and clubs, this system maintains unyielding acoustic stability whether delivering high-intelligibility speech, detail-rich live performances, or high-dynamic DJ sets.
Technical Specification
AES Power Handling
- LF : 500
- HF : 60
Program Power
- LF : 1000W
- HF : 120W
Nominal Impedance
- 6 ohm
Transducers
- LF : 1x12" neodymium
- HF : 1x1.7" neodymium
Acoustic Modes
- LF: Bass-reflex
- HF: CD Horn
Pin Assignment
- 1+/1-(INPUT) ,2+/2- (Link)
Nominal Directivity (-6 dB)
- Horizontal: (90°)
- Vertical: (60°)
Connectors
- 2x4-points Speakon®
Splay Angles
- Fixed angle
Rigging Hardware
- Optional dedicated vertical hanger and dedicated horizontal mounting brackets
Cabinet Coating
- All-birch plywood with black polyurea wear-resistant finish
IP Rating
- IP55
Rigging Points
- M8
Bandwidth
- 45 Hz - 18 kHz
Maximum SPL
- LF : 130 dB
- HF : 132 dB
Sensitivity (1 W / 1 m)
- LF : 96.5 dB
- HF : 108.5 dB
Dimensions (W x H x D) mm
-
365x645x326 mm
(14.4"x25.4"x12.8")
Net Weight
- 21 kg (46.3 lbs)
Product Code
- 12323700208905
Download
| Download | |||
|
K2指向性图/频率响应曲线
updated: 2026-05-08
|
355.53 KB | ||
|
K2系统建议图
updated: 2026-04-03
|
832.22 KB | ||
|
K2系统 2D CAD
updated: 2026-03-19
|
617.53 KB | ||
|
K2系统 2D CAD
updated: 2026-03-19
|
rar | 491.41 KB | |
|
K2系统 3D CAD
updated: 2026-05-08
|
rar | 523.27 KB | |
|
K2系统 Sketchup
updated: 2026-05-08
|
rar | 437.87 KB | |
|
产品保修卡
updated: 2025-12-25
|
171.68 KB | ||
|
产品天气防护
updated: 2025-12-27
|
400.75 KB |
Application System
